Test Case Includes Too Many Branches

Rule ID: TA-DBP-007

Scope: Workflow


This rule checks if a test case is using any If statements. The default is set to 0. This is applicable to the following activities:
  • If
  • Switch
  • Flow Decision
  • Important: You can apply this rule only for test cases that have been published. This helps you to exclude template files or temporary backups.


Consider having a specific test focus and a clear outcome by testing only one variation of a certain process at a time.

Configure Rule

  1. In the Design ribbon, navigate to Analyze File > Workflow Analyzer Settings.
  2. Go to Workflow Analyzer to view the rules.
  3. Select Test Case Includes Too Many Branches and configure the default action.

  4. Set a Maximum Number of Allowed Branches value.
  5. Click OK to save changes.

Reset to Default Value

To reset the rule to the default configuration, right-click it and select Reset to default. This resets the "Maximum Number of Allowed Branches" to 0.
  • Description
  • Recommendation
  • Configure Rule
  • Reset to Default Value
