Send SMS

UiPath.Upwire.Activities.SendSms

The Send SMS activity uses one of your Upwire purchased numbers or approved alphanumeric callerIDs (From) to send an SMS message to a specified number (To). In addition to a simple string messages, you can also send a PIN for authentication.

Summary

Dependency

Dependency	Details
Packages	UiPath.Upwire.Activities
Activities	Upwire Scope

Attributes

Attributes	Details
Inputs (Variables)	String Applies to property: From, To, and Message
Outputs (Variables)	N/A
Examples	Quickstart

Properties

The values for the following properties are specified when adding this activity to your project in UiPath Studio.

Common

DisplayName

The display name of the activity.

Attributes	Details
Type	String
Required	Yes
Default value	Send SMS
Allowed values	Enter a String or String variable.
Notes	N/A

Input

From

The Upwire purchased number or approved alphanumeric callerID that the message is sent from.

Attributes	Details
Type	String
Required	Yes
Default value	Send SMS
Allowed values	Enter a String or String variable.
Notes	You can only use a number that was purchased from Upwire and/or an alphanumeric callerID that was approved by Upwire. For more information, see the Upwire website.

Message

The message content to send.

Attributes	Details
Type	String
Required	Yes
Default value	Empty
Allowed values	Enter a String or String variable.
Notes	To send a generated PIN, select the GeneratedPin checkbox and add [[PIN]] in the message string.

To

The mobile number that you want to receive the message.

Attributes	Details
Type	String
Required	Yes
Default value	Send SMS
Allowed values	Enter a String or String variable.
Notes	The number must start with a valid country code. Enter number values only; do not include spaces, dashes (-), or other characters (e.g., +)

Misc

Private

If selected, the values of variables and arguments are no longer logged at Verbose level.

Attributes	Details
Type	Checkbox
Required	No
Default value	Not Selected
Allowed values	Selected or Not Selected
Notes	N/A

Options

GeneratedPin

If selected, adding [[PIN]] in the Message is replaced with a generated code.

Attributes	Details
Type	Checkbox
Required	No
Default value	Not Selected
Allowed values	Selected or Not Selected
Notes	You must include [[PIN]] in the Message when this property is selected, otherwise the recipient will not see the generated code.

GeneratedPin

The type of GeneratedPin that you want to generate.

Attributes	Details
Type	Drop-down list
Required	No (If GeneratedPin is selected, this property is required)
Default value	Numeric
Allowed values	Select either Numeric or Alphanumeric
Notes	N/A
