Procedure

1. Add a required chart with the needed data in an Excel sheet.
2. Use the Get Excel Chart activity to save the chart.

3. Save the chart as a picture.








4. Use the Load Image activity and reference the chart image location.
5. Convert the chart image to base64.
7. Pass the string as an out argument of your choice.

8. Value bind the out argument to your image control in UiPath Apps.
